Specifications:

• Outputs: 4
• Frequency range:
• VHF band: 40-318 MHz
• UHF band: 470-862 MHz
• Gain:
• VHF band: 20 dB+TOL (+1.0)
• UHF band: 28 dB (+2.0)
• Planarity Response: +0.8 dB
• Gain Adjustment: 16 dB
• Output Level: 12 dBμV
• Isolation between Outputs: -10 dB
• I/O Return Loss: -10 dB
• Chroma - Luminance Delay: <11 ns
• Noise Figure: 4.2 dB (+0.2)
• Supply Voltage: 230 V~ ±10% 50/60 Hz
• VA: 7.2
• Operating Temperature: -10..+65 °C
• Protection Index: IP 20
• Units per Pack: 1
• Package Weight: 0.58 kg
• Package Dimensions: 165 x 100 x 50 mm
