HTW-TV-050SMPLUS

• EAN: 8435483845725
• Power supply: 220–240V (1 Phase ~ 50/60Hz)
• Power: 2000 W
• Current: 8.3–9.1 A
• Declared profile: M
• Energy class: B

Performance

• Capacity: 50 L
• Maximum working pressure: 0.75 MPa
• Operating temperature: 30 ~ 75°C
• Recovery time (15→40 °C): 43 min
• Annual electricity consumption: 1261.3 kWh

Features

• Insulation thickness: 25 mm
• Insulation material: Polyurethane
• Material thickness: 1.8 mm
• Coating: Electrostatic dry powder
• Protection rating: IPX4
• Anode: Electronic
• Resistance: Incoloy 840
• Installation type: Vertical
• Water inlet: ½”

Dimensions and Weight

• Net dimensions (Ø × H): Ø 390 × 778 mm
• Gross dimensions: 465 × 845 × 465 mm
• Net weight: 17.1 kg
• Gross weight: 19.7 kg
